Racepak

Racepak V500SD Data Recorder 200-KT-V500SD

$3,215.00
SKU:
200-KT-V500SD
Shipping:
$25.00 (Fixed Shipping Cost)
Current stock: 0
Description

Description

The V500SD data recorder is the most common recorder for Pro Stock, Pro Modified and many of the Sportsman classes. In its base configuration, the V500SD monitors six parameters (Engine RPM, Driveshaft RPM, Accel G, Lateral G, Battery Volts and a 12-volt event), but it can be expanded to monitor up to 71 channels of data plus an additional 56 channels dedicated to monitoring Smartwire channels. Like the V300SD , the V500SD can sample data on its analog port up to 1000 times per second.

Uploading recorded data to your computer is done via a SD memory card, which provides you with hours of recording time and the ability to store many runs prior to uploading the data. The V500SD also has multiple methods of displaying monitored data in real time. When linked by serial cable to your PC or wirelessly using the option Bluetooth upgrade you can view all recorded functions in either graph format or on 8 virtual gauges while the vehicle is running. The unit also supports the use of our optional Intelli-Gauges or either the IQ3 or Ultra Dash (UDX). The V500SD can be equipped to monitor overall timing, or individual cylinder timing on those vehicles using the proper programmable ignition system.

Channels:
75 total
V-Net: 56
Smartwire: 56
Analog: 4 hard-wired
Digital: 8 hard-wired
Internal: 3

Sample Rates:
V-Net: up to 100 per second
Analog: up to 1000 per second
Digital: RPM and switch contacts up to 100 per second
Digital: Timing intervals within 1/1000th of a second

Memory:
SD memory card
Recording time depends on number of channels monitored and sample rates

Internal Sensors:
Battery Voltage
Longitudinal g-meter (acceleration and deceleration)
Lateral g-meter (side-to-side motion)

Dimensions:
5.350” (L) X 5.550” (W) X 1.215” (H)

Weight:
17 ounces
